| Motor supply | 230 Vac (50-60Hz) |
| Max absorbed current | 1.4 A |
| Max Thrust | 3500 N |
| Opening time | 26” |
| Duty cycle | 30% |
| Standard stroke | 455 mm |
| Max stroke | 520 mm |
| Protection level | IP44 |
| Encoder | NO |
| Operating temperature | -20°C /+50°C |
| Leaf max dimension | 5 m |
| Weight | 11.6 kg |
| Items no. per pallet | 30 |
Contact our technical team to find the right kit for your product.
