| Code | 9591534 |
| Power supply | 230 Vac (50-60Hz) |
| Motor supply | 230 Vac |
| Max absorbed current | 1.5 A |
| Max Thrust | 1800 N |
| Opening time | 18” |
| Operation cycle | 30% |
| Standard stroke | 270 mm |
| Max stroke | 325 mm |
| Protection level | 325 mm |
| Protection level | IP44 |
| Encoder | NO |
| Operating temperature | -20°C /+50°C |
| Leaf max dimension | 2.1 m |
| Weight | 8.2 kg |
| Items no. per pallet | 54 |
| Kits no. per pallet | 18 |
Contact our technical team to find the right kit for your product.
